Cree LED's UHD111A RGB LEDs are engineered for indoor display applications delivering high brightness, a wide viewing angle and high contrast to produce vivid colors, crisp text and detailed graphics.
UHD111A 3-in-1 RGB LED for Fine-Pitch Indoor Video Displays
The UHD111A is a compact 3-in-1 RGB LED designed for fine-pitch indoor LED video displays and high-resolution video walls where excellent image quality and consistent color are essential. Its ultra-small 1.0 × 1.0 mm package enables display manufacturers to build high-density LED video walls with finer pixel pitches, sharper images and seamless visual performance.
Engineered for indoor display applications, the UHD111A delivers high brightness, a wide viewing angle and high contrast to produce vivid colors, crisp text and detailed graphics. The matte package surface helps reduce reflections and improve perceived contrast, enhancing image quality in environments with ambient lighting.
Applications
The UHD111A is optimized for:
- Fine-pitch indoor LED video walls
- Full-color indoor video displays
- Broadcast studios
- Corporate and control room displays
- Retail and commercial digital signage
- Hospitality displays
- Decorative RGB lighting
- Entertainment and amusement lighting
Key Features of UHD111A LEDs
- Ultra-compact 1.0 × 1.0 mm 3-in-1 RGB LED package
- Designed for fine-pitch indoor LED displays
- High brightness for vibrant image reproduction
- Wide viewing angle for consistent image quality
- Matte package surface to reduce reflections and improve contrast
- High-contrast design for enhanced black levels and readability
- Moisture Sensitivity Level (MSL): 5a
- Lead-free and RoHS compliant
Optical Specifications
Color Dominant Wavelength Luminous Intensity
Red 617–622 nm 29–38 mcd @ 5 mA
Green 524–528 nm 51–66.5 mcd @ 3 mA
Blue 465–469 nm 10.7–14 mcd @ 3 mA
Why choose UHD111A LEDs?
The UHD111A is designed for manufacturers building next-generation indoor LED displays with fine pixel pitches and exceptional image quality. Its compact package supports higher display resolution, while its high brightness, wide viewing angle and high-contrast design help deliver clear, vibrant images for applications ranging from broadcast studios and corporate environments to retail displays and indoor video walls.
